The only 4-person infrared sauna engineered to deliver full-spectrum heat and integrated red light therapy in a spacious, dual-bench design. The FD-5 combines commercial-grade infrared, medical-grade LEDs, and premium cedar — built for serious daily use and complete comfort.
Features
- Heats to 170°F – ideal for full-body sessions in a larger cabin
- Dual infrared system: Carbon 360° far-IR + UL-listed Spectrum Plus™ near-IR
- Built-in 650nm red light therapy – targets recovery, inflammation, and skin health
- Digital touchscreen control with WiFi remote app access
- Bluetooth audio with premium 6" built-in speakers
- Constructed from antimicrobial Western Red Cedar (interior) and rot-proof Thermal Plus™ Aspen (exterior)
- ETL safety certified with ultra-low EMF heaters
- Assembles in under 60 minutes – no special tools or installers required
Specifications
| Category | Detail |
|---|---|
| Capacity | 4 person |
| Exterior Dimensions | 75″ W x 64″ D x 83″ H |
| Interior Dimensions | 71″ W x 57.5″ D x 75.5″ H |
| Volume | 130 cu. ft. |
| Weight | 575 lbs (Shipping: ~840 lbs) |
| Wood Type | Interior: Western Red Cedar; Exterior: Thermal Plus™ Aspen |
| Glass | 8mm tempered glass door |
| Heating System | Full-spectrum: Carbon far-IR + Spectrum Plus™ near-IR |
| Infrared Output | 2.7 kW |
| Max Temperature | 170°F |
| Red Light Therapy | Integrated ceiling-mounted 650nm LED array |
| Control Panel | Touchscreen digital panel w/ WiFi app control |
| Lighting | Chromotherapy LEDs |
| Audio | Bluetooth receiver, dual 6” built-in speakers |
| Electrical Setup | 240V / 15A dedicated household circuit; NEMA 6-15 plug for IR; hardwired 240V / 20A circuit required for traditional heater if included |
Construction & Materials
- The FD-5 features a double-walled cabin lined with Grade-A Western Red Cedar — naturally antimicrobial and aromatic — and a Thermal Plus™ Aspen exterior that will never rot, warp, or decay. The walls are insulated for maximum heat retention and energy efficiency. Its 8mm tempered glass door provides durability and a clean aesthetic.
Installation
The FD-5 is designed for indoor use only and fits under standard ceilings. It assembles in 60 minutes with two people. Infrared system plugs into a 240V outlet using the included NEMA 6-15 plug. If using a traditional heater (optional), a hardwired 240V / 20A circuit is required. Panels lock together via pre-fitted hardware, and the bench system installs tool-free. Adjustable leveling feet included.
Operation & Usage
Once plugged in, use the touchscreen or app to power on, set temperature (up to 170°F), and choose session duration (up to 60 minutes). Red light therapy is built in. Preheat time is ~20–30 minutes depending on ambient temperature. No plumbing or venting needed. The large two-level bench system allows flexible seating for 1–4 people.
EMF & Safety
The FD-5 is built with safety at its core:
- Ultra-low EMF output, third-party tested
- ETL certified to UL/CSA electrical safety standards
- Built-in overheat protection and session timer
- Zero off-gassing materials or adhesives
- Ideal for daily use in residential settings.
