Patented Air-Blending Climate Equalizer
The Saunum AIR 5 combines a 4,950-watt heater with an integrated climate equalizer. It blends hotter ceiling air with cooler lower air and returns the mixture to help reduce temperature stratification.
Designed for 106–212 Adjusted Cubic Feet
This Nordic Black closed-basket model serves 106–212 adjusted cubic feet. Glass, masonry, insulation, and ventilation affect sizing; calculate effective volume with the current manual.
Large Stone Mass and Adjustable Height
The closed basket holds 110 pounds of rounded 2–4″ stones. Its telescoping hot-air intake adjusts the assembled height from 73–95″ to meet the ceiling as directed.
Integrated Salt Tray and Three-Speed Fan
Seven Himalayan salt spheres sit in a removable airflow tray. The three-speed fan distributes blended air and steam under the manual’s operating and safety instructions.
Key Features
- 5kW marketed output; 4,950W rated
- For 106–212 adjusted cu. ft. sauna rooms
- Patented air-blending system helps reduce temperature stratification
- Nordic Black closed stone basket with 110 lb stone capacity
- Adjustable 73–95″ height; 73″ minimum ceiling
- Integrated three-speed climate-equalizing fan
- 240V, single-phase, 20.63A
- Saunum AirIQ control and compatible stones required and sold separately
- UL Certified to UL 875; Canadian certification to CSA C22.2 No. 164
What’s Included
- AIR 5 4,950W heater with Nordic Black closed basket
- Heat equalizer, telescopic intake, cap, grille, and three element air tunnels
- Seven Himalayan salt spheres and removable tray
- Supplied heater/equalizer cables, temperature sensor, door sensor, and AirIQ panel cable
- Quick guide, installation manual, and limited warranty
Required Components Sold Separately
- Compatible Saunum AirIQ control system
- 110 lb of rounded 2–4″ sauna stones; supplier recommends four boxes
- Installer-selected supply cable, protection, and materials
Control, stones, field wiring, electrical work, installation, safety rail, air deflector, aroma products, and Auto Leil are not included.
Specifications
| Brand |
Saunum |
| Model |
AIR 5, closed basket |
| SKU / MPN |
4745090017830 |
| GTIN / EAN-13 |
4745090017830 |
| Finish |
Nordic Black steel |
| Power |
5kW marketed; 4,950W rated |
| Sauna room range |
106–212 adjusted cu. ft. (3–6 m³) |
| Electrical supply |
240V, single-phase |
| Current draw |
20.63A |
| Manual-listed breaker |
30A |
| Manual-listed supply |
(2) #10 + neutral + ground; installer/code verification required |
| Required control |
Saunum AirIQ control system; sold separately |
| Stone requirement |
110 lb (50 kg) of rounded 2–4″ (5–10 cm) stones; sold separately |
| Dimensions |
18.3″ W × 12.5″ D × adjustable 73–95″ H |
| Product weight |
147 lb |
| Installation |
Permanent upright wall installation with adjustable feet; hardwired |
| Clearances |
2″ sides/front; 40″ basket-to-ceiling; 20″ at fan output; manual governs |
| Construction |
Steel body and closed Nordic Black stone basket; Incoloy heating elements |
| Certification |
UL Certified to UL 875; Canadian certification to CSA C22.2 No. 164 |
| Warranty |
2-year limited private-use warranty; elements and salt spheres excluded |
Electrical and Installation Requirements
Qualified professionals must install and connect the heater under the current Saunum manual, NEC, and local codes. The manual lists a 30A breaker and (2) #10 conductors plus neutral and ground; the installer must verify all requirements.
Intake and exhaust ventilation are mandatory. Maintain clearances, keep the fan outlet open, and position the AirIQ control and sensors as directed.
Warranty
Saunum provides a 2-year limited private-use warranty. A completed installation report and qualified electrical installation are required. Labor, elements, salt spheres, wear, misuse, improper installation, and other stated exclusions are not covered. Current terms govern.
Shipping and Lead Time
Ships by scheduled LTL freight at actual cost. Confirm inventory, freight, access, delivery terms, and the approximate 60-day lead time before purchase.
